Shimpo DT-329 Stroboscope
Our Price: CALL FOR PRICING
Item Number: DT-329
Manufacturer: Shimpo
Part Number: DT-329
|
|
Shimpo DT-329 Stroboscope
No other strobe on the market delivers a crisper, clearer image across all flash rates with such a high brightness. From its LED technology, even at ultra high cycle rates to 120,000 (FPM), the service life of the DT-329 is 5x’s greater than many traditional stroboscopes which incorporate xenon flash tubes. Unlike xenon flash tubes, the LED’s produce no sound when in use; an added benefit and perfect for audio and speaker research. The DT-329 is ideal for wide and narrow web printing, motion and machine vibration analysis, audio (speaker) research, pulp and paper manufacturing and a wide range of rolling mill applications. Easy to mount and set up, the DT-329’s design provides for daisy chain and external triggering methods. Phase shifting (flash advance/delay in degrees and mSec), external and internal flash control, and a back-lit LCD display provides the operator an easy to use visual inspection tool to monitor production quality under all line speeds.
Features
- High flash rate, 60 – 120,000 fpm (1 – 2000 Hz)
- High brightness, 1,950 lux at 120,000 fpm @ 7.87in (20 cm) to target
- Large “Illuminated” Area, 23.62 in x 15.75 in (600 mm x 400 mm)
- Silence, no noise, no flash tubes
- Simple flash setting control by dial, push button or external trigger
Technical Specifications
| Model |
DT-329 |
| Unit FPM (Flashes Per Minute) |
Hz |
| Flash Rate Range |
High Range |
60 – 120,000 FPM, 1 – 2,000Hz |
| Low Range |
60 – 12,000 FPM, 1 – 200Hz |
| Flash Rate Accuracy |
0.02 % ± 1 digit at 77°F (25°C) |
| Flash Rate Range |
Unit FPM |
High Range |
1 FPM |
60 – 30,000 FPM |
| 2 FPM |
30,002 – 60,000 FPM |
| 5 FPM |
60,005 – 100,000 FPM |
| 10 FPM |
100,010 – 120,000 FPM |
| Low Range |
0.1 FPM |
60.0 – 3,000.0 FPM |
| 0.2 FPM |
3,000.2 – 6,000.0 FPM |
| 0.5 FPM |
6,000.5 – 12,000.0 FPM |
| Unit Hz |
High Range |
0.1 Hz |
0.1 – 2000 Hz |
| Low Range |
0.01Hz |
0.01 – 200 Hz |
| Ratio (Flash Duty) |
0.1 – 2.5° (/ 360°) Setting of every 0.1° |
| Light Source |
High Brightness LEDs |
| Flash Delay |
Time: 0 – 999 ms; Angle: 0 – 359° |
| External Trigger Input |
Photocoupler input 12mA/DC12V |
| External Clock Output |
Photocoupler Output 30mA/DC30V, Pulse width 200μs |
| Light Power (Illumination/Brightness) |
1,250 lux |
6,000 FPM |
7.87in (20cm) |
| 700 lux |
19.69in (50cm) |
| 1,950 lux |
120,000 FPM |
7.87in (20cm) |
| 860 lux |
19.69in (50cm) |
| Display |
LCD with Backlight |
Main Display: 6 characters |
| Sub-display: Flash, Units, Battery, Settings |
| Power Supply |
AC 100V – 240V 50/60Hz |
| Operating Temperature |
32° – 95° F (0 – 30° C) |
| Dimensions |
N/A |
| Product Weight |
11 lbs (5 kg) |
| Package Weight |
17.6 lbs (7.98 kg) |
| Warranty |
2-Year |
| Included Accessories |
AC cable, 1 Input Connector, 1 Output Connector, Manual, Warranty Card |
|
