Kanomax S320 Handheld Multi-Gas Monitor
|
Item Number: S320
Manufacturer: Kanomax
Part Number: S320
|
|
Kanomax S320 Handheld Multi-Gas Monitor
The Series 320 is supplied in an FRP enclosure and provides a high level of functionality & monitoring capability.
Features
- These Handheld Air Quality Monitors can be supplied in FRP Enclosures rendering them tamperproof and providing additional protection from dust and water droplets.
- Interchangeable sensor heads capable of measuring more than 20 types of toxic gases
- Remote sensor capability
Applications
- IAQ Investigation
- Industrial Hygiene Quality Control
- Occupational Safety and Health Testing
Technical Specifications
Model
|
Series 320 |
Series 520 |
Measurments Units
|
ppm or mg/m3ppm or mg/m3
|
Sensor Head
|
Removable and Replaceable
|
| External signal for alarms & Control |
Transistor output, 150mA max |
| Functions |
- On-board alarm
- Alarm status displayed
- Low battery indication
- Sensor condition status
- Stand-by mode
- Remote sensor capability
|
Analog output
|
0 to 5 V
|
| Digital output |
n/a |
RS232C |
On-board data logging
|
n/a |
8000 data points |
Power Supply
|
Battery or 12VDC, 800mA
|
Battery Type
|
Rechargeable battery pack
Ni-MH: 9.6V, 5 hours operation
|
Dimensions
(with sensor head)
|
7.0 x 4.75 x 2.0 inches (195 x 122 x 54 mm)
|
Weight
(with sensor & battery)
|
< 0.4 lbs (460 g)
|
|
Kanomax Gasmaster Sensor Head are interchangeable sensor heads are available for over 30 gases, including formaldehyde and VOCs.
|
Kanomax S300 has on-board alarm and analog output.
|
Kanomax S520 is supplied in an FRP enclosure, is functionality rich and has the added feature of onboard and PC data logging.
| |
