GW Instek SPS-606 Switching DC Power Supply
|
Item Number: SPS-606
Manufacturer: GW Instek
Part Number: SPS-606
* Whole number only
|
|
GW Instek SPS-606 Switching DC Power Supply
The SPS-Series are single output, 360W, switching DC power supply. OVP protects the SPS-Series and their load from unexpected conditions. High regulation is maintained at 0.01%. Remote sensing adds extra level of precision by compensating cable losses between loads. Turning the output On/Off from external device is available through remote control terminals. The SPS-Series are an ideal solution for power-efficient bench-top or portable applications requiring high regulation.
Features
- Dual Measurement Display
- 0.01 % High Regulation
- Constant Voltage and Constant Current Operation
- High Efficiency
- High Power Density
- Over Voltage Protection
- Remote Output ON/OFF Control
Technical Specifications
| OUTPUT |
|
|
SPS-1230
|
SPS-1820
|
SPS-2415
|
SPS-3610
|
SPS-606
|
|
Voltage
|
0~12V
|
0~18V
|
0~24V
|
0~36V
|
0~60V
|
|
Current
|
0~30A
|
0~20A
|
0~15A
|
0~10A
|
0~6A
|
| CONSTANT VOLTAGE OPERATION |
| Line Regulation |
< 5mV |
| Load Regulation |
< 5mV |
| Ripple & Noise |
< 5mVrms, 100mVp-p 20Hz ~ 20MHz |
| Recovery Time |
< 500μS ( 50% Load change, Minimum load 0.5A ) |
| Temp. Coefficient |
< 100 ppm/°C |
| Output Range |
0 to rating voltage continuously adjustable |
| CONSTANT CURRENT OPERATION |
| Line Regulation |
< 3mA |
| Load Regulation |
< 3mA |
| Ripple Current |
< 3mArms (SPS-606)
< 5mArms (SPS-3610)
< 10mArms (SPS-2415)
< 10mArms (SPS-1820)
< 30mArms (SPS-1230) |
| Output Range |
0 to rating current continuously adjustable (Hi/Lo range switchable) |
| METER |
| Type |
3 1/2 Digit 0.39" LED Display |
| Accuracy |
±( 0.5% of rdg + 2 digits ) |
| INSULATION |
| Chassis and Terminal |
20MΩ or above (DC 500V) |
| Chassis and AC Cord |
30MΩ or above (DC 500V) |
| POWER SOURCE |
| |
AC 115V/230V ±15%, 50/60Hz |
| DIMENSIONS & WEIGHT |
| |
128(W) x 145(H) x 285(D)mm
Approx. 3.2kg |
|
GW Instek SPS-2415 output is 24V(Voltage) and 15A(Current).
|
GW Instek SPS-1820 output is 18V(Voltage) and 20A(Current).
|
GW Instek SPS-3610 Outputs: 0~36V(Voltage), 0~10A(Current).
|
GW Instek SPS-1230 output is 12V(Voltage) and 30A(Current).
|
