Shimpo Instruments FGV-X DART 2.0 Series Digital Force Gauge
Our Price: CALL FOR PRICING
Item Number: FGV-XY
Manufacturer: Shimpo
Part Number: FGV-XY
|
|
Shimpo Instruments Force Gauge - FGV-X DART 2.0 Series
The all NEW Shimpo FGV DART 2.0 series gauges from SHIMPO combine the extensive features of the SHIMPO DFS series with the rugged, ergonomic and compact design of the original DART series to provide a complete force testing instrument for a variety of industries. With free software and toriemon USB, the FGV-XY provides a total package for force testing up to 200 lbs.
The ergonomically designed DART 2.0 provides an easy to use force gauge for incoming quality inspection, finished goods testing, R&D and other force-related applications. Onboard statistic calculations provide fast access to maximum, minimum, average and standard deviation data.
The USB port and 1,000 point memory allows for data to be easily exported in real time or once testing is complete. In addition, the RS-232C and analog outputs allow the DART 2.0 series maximum flexibility.
Applications where the Shimpo FGV DART 2.0 force gauge excels: Wallboard, wire pull, wire crimp, trigger pull, brake pedal, aerospace ceramic, spring, food ripeness, corrugated paper strength, blister pack medical component, muscle strength and ergonomic testing.
Features Benefits - Shimpo FGV Force Gauge
- 1000 Hz Sample Rate provides faster sampling producing better resolution and more accurate results
- High accuracy +/-0.2% F.S., ideal for strict tolerances
- Measure and record compression and tension tests- permits true “push-pull” testing
- 180° Reversible display and dual printed keypad allows usage as a portable gauge or mounted upside down on a test stand
- Maximum data collection flexibility with 3 outputs: USB, RS-232 & Analog Output
- 1 million operation load cell with superior overload protection provides a long-life, damage free product
- Rugged, ergonomic die cast aluminum construction allows usage on production floor
- On board statistics provides immediate results and analysis of test data
- Variable display response rate aids viewing readings
- Expanded memory for reviewing data points and transferring to PC/Laptop
- Built-in Hi-Lo Comparator function provides user with easy ‘Go-No Go’ Testing
- Quick retrieval of peak measurement with a single push button
- Flexible user preference with one button selection of up to 4 engineering units
- Dual power capable with rechargeable battery or AC line voltage
- Field Calibration through keypad eliminates down time
- CE Mark
  |
