Reed R5002 Insulation Tester Megohmmeter
|
Item Number: R5002
Manufacturer: Reed Instruments
Part Number: R5002
Product Options
Reed R5002 Calibration Options
* Whole number only
|
|
Features
- Wide range measurements from 500V to 5000V and up to 60 GΩ
- Sources up to 1.2mA current during tests to offset capacitance load
- Polarization index measurement (PI)
- Dielectric absorption ratio measurements (DAR)
- Time set measurement function
- Auto-discharge function and voltage output warning function
- Live circuit warning symbols plus audible warning
- Live circuit detection prevents insulation test if >30V is detected
- Max/Min, Peak, Relative value and Data Hold functions
- 6000-count digital display with bargraph and backlight
- Meets IEC61010-1 Cat. IV 600V safety standards
- Includes test leads, batteries and carrying case
|
