Newport Bolt-On Washer Thermocouple Assemblies
Features:
- Proven Rugged Design
- For #6, #8, #10 and 1/4" Screw Sizes
- Made from 20 AWG Glass-On-Glass or Teflon® Insulated Special Limits of Error Wire
- Available in 12, 24, 36 and 60" Lengths with Stripped End Leads (Call for Special Lengths)
- Rated to 480 Deg C (900 Deg F)
Washer Dimensions:
- #6 and #8 screw size: 0.875" L x 0.250" W
- #10 and 1/4" screw size: 1" L x 0.360" W
Available in custom sizes and applications, Call with your specific needs.
|
