Kobold NLP Hydrostatic Pressure Level Switch
Our Price: Call or Chat for Pricing Quote
Item Number: NLP
Manufacturer: Kobold Instruments, Inc.
Part Number: NLP
FREE SHIPPING IS NOT AVAILABLE FOR THIS PRODUCT
* Whole number only
|
|
FREE SHIPPING IS NOT AVAILABLE FOR THIS PRODUCTKobold NLP Hydrostatic Pressure Level Switch
The KOBOLD NLP Hydrostatic Pressure Level Switch excels at level control in open tanks where suspended solids are present. Operation of the switch is based upon the change in hydrostatic pressure within the standpipe. When the media rises or falls to the desired level, the changing air pressure within the tube reacts on the internal diaphragm, actuating or de-actuating the SPDT contact within the switch housing. The KOBOLD NLP has no moving parts, requires no external power, operates with minimal maintenance, and is suitable for a wide variety of media.
Features
- Suitable for a wide variety of free-flowing liquids in open tanks
- No moving parts
- Polypropylene or PVDF wetted parts
- No external power required
- Minimal maintenance required
Technical Specifications
| Fitting |
1" NPT, G1 |
| Max. Process Temp. |
158 °F |
| Switching Range |
Up to 16 ft |
| Switch Rating |
250 VAC 1A |
|
