Extech 381285 5 MHz Multiscope and TRMS Multimeter

Features:

Oscilloscope

• 160x160 pixel high density graphical display with 2.5 x 2.5" viewing area and backlighting
• DC to 5MHz bandwidth and 25 MSPS sampling rate
• Vertical sensitivity of 10mV to 200V per division with 14 divisions displayed
• Single channel with 1 M-Ohm input impedance
• Horizontal sweep rate of 125 ns to 2s per divisions with 23 divisions
• Adjustable trigger level and slope
• Single shot mode with waveform expansion or compression
• Cursor function measures time or voltage two point differences on a waveform

MultiMeter

• 4000 count dual display with analog bargraph
• True RMS AC Voltage and Current
• Functions include AC/DC Voltage and Current, Resistance, Capacitance,
  Frequency, dBm, Diode and Continuity
• Max/Min/Average with time stamping and graphical plot
• Auxiliary feature allows for direct temperature, humidity or high current
  displays using external dmm adaptors
• High/Low comparator feature in the voltage, resistance or auxiliary functions
• Frequency Counter function with simultaneous frequency, period and rpm display
• 5V square wave output is adjustable from 2.5Hz to 78kHz
• Automotive rpm, duty cycle, dwell and ms pulsewidth displays
• Graphical logic analyzer function

General

• Store up to 15 screens or text displays
• RS-232 PC interface with Windows® 95/98/2000/ME/XP compatible software
• Auto Power Off
• Optional rechargeable NiCad battery pack and AC adaptor/recharger recommended
• Complete with protective holster, built-in stand, Windows® compatible software,
  RS-232 cable, six AA batteries, fuses, test leads & alligator clips
