Ashcroft DXLdp Low Differential Pressure Transmitter

Ashcroft DXLdp Low Pressure Differential Transducer/Transmitter

The Ashcroft Si-Glas sensor now enables precise measurement and control of very low pressure. Although the ultra-thin silicon diaphragm deflects only a micron, the sensor is 100 times more sensitive to pressure than available silicon piezoresistive pressure sensors.  The Si-Glas sensor is composed of only sputtered metals and glass molecularly bonded to silicon. There are no epoxies or other organics in the sensor to contribute to drift or mechanical degradation over time. The glass-clad silicon diaphragm withstands extreme overpressure as well as severe shock and vibration.



• The exclusive patent pending Ashcroft® SpoolCal™ actuator provides in-place system calibration without disturbing process tubes
• Front access test jacks provide on-line signal reference without removing wiring
• LED range status indicators for instant troubleshooting information
• DIN Rail Mount – dramatically reduces installation and calibration costs
• CE standard with all outputs
• On-board voltage regulation allows use of lower cost, non-precise, unregulated power supply

• High reliability:
  HVAC
  Bio-pharm
  Bio-tech
  Room pressurization and control
  Environmental pollution control
