Ametek Jofra CPC Compact Pressure Calibrator

Ametek Jofra CPC Compact Pressure Calibrator


The Ametek CPC Calibrator in Action!

     The Ametek Jofra CPC calibrator series is the new generation of the successful AMETEK series of pressure calibrators.  The CPC series is recognized by its high quality and carefully selected features that save time and make calibration tasks easy to perform; e.g. dual information display, 11 different pressure units,transmitter mA reading, min/max recording, peak reading, and semi-automatic pressure switch testfinding the closing, opening and the hysteresis pressure (dead band).

     Maintenance of the instrument is made easy.  Re-calibration of the unit canbe performed locally with an accurate pressure reference: No need to sendthe unit back to the manufacturer for re-calibration.  For all systems thepump and the indicator are seperate so replacement of the pump does not mean that you have
to send the complete system for repair. JOFRA CPC can be delivered as an individual indicator or as a complete calibration system ready for use in a carrying case, including pump, hose, connectors, battery, test leads, user manual, and traceable calibration certificate.

Features:

• Available in Three Ranges: 10, 30, 200 PSIG
• Reads Vacuum
• Reads out in 11 Engineering Units
• +/-0.05% FS Accuracy
• Reads Loop Current up to 24 mA
• Dual LCD Display Reads Pressure & mA
• Records MAX & MIN Readings
• Switch Test Records Opening & Closing Pressure
• Can be Recalibrated in the Field
• Can be supplied as a complete system with Pump

CPC system A This ready-to-use calibration system comes with an AMETEK pneumatic pump series T-700. The type of pump depends on the operating ranges required. Systems are available for vacuum to 0.7, 2 or 15 bar / 10, 30, or 200 psi. All systems have built-in fine adjustment, vent valve, and separate output for the test object and are delivered with a traceable calibration certificate.

CPC system B This 'ready-to-use' calibration system comes with an AMETEK pneumatic pump series T-910. This type of pump has both vacuum and pressure capabilities. System B cover the pressure range vacuum to 15 bar / 200 psi. The system has built-in fine adjustment, vent valve, and separate output for the test object and are delivered with a traceable calibration certificate.
