AEMC FlexProbe Flexible Current Probe Model 24-3002 (3000 Amps AC)
Our Price: Unit has been discontinued. REPLACED BY 24-3001
Item Number: 2120.82
Manufacturer: AEMC (Chauvin Arnoux)
Part Number: 2120.82
|
|
AEMC FlexProbe Current Probe Model 24-3002 (3000 Amps AC) The FlexProbe® Models 24-3001 and 24-3002 are low cost AC current measurement probes designed to plug into digital multimeters, oscilloscopes, and power recorders.The Model 24-3001 is composed of a flexible sensor and an electronic module with a 14" double insulated cable, while the Model 24-3002 has aflexible sensor and an electronic module with 4mm safety banana plugs with 3/4" spacing. The flexible sensors are designed to fit around large or small conductors and are capable of getting into tight or difficult places.They are ideal for measuring AC current in a group of conductors.
Features:
-
24" flexible sensor fits around conductors up to 7.6" in diameter
-
Dual measurement ranges of 300A and 3000 AAC
-
Read amperage directly on DMM display
-
mV output directly proportional to the AC current measured
-
Output is 10mV/A on 300A range and 1mV/A on 3000A range
-
Accuracy of 1% of Reading +/- 500mA
-
4% influence of conductor position in jaw
-
Up to 300 hour battery life
-
Dual banana plug termination for direct input into DMMs (Model 24-3001)
-
Electronic module with 4mm safety banana plugs with 3/4" spacing (Model 24-3002)
-
EN 61010, 1000V Cat. III, Pollution Degree: 2
-
Flashing LED low battery indicator
Applications:
|
