AEMC Model SR652 AC Current Probe (1000A, 1mV/A, Lead)
Our Price: Unit has been discontinued. Please call (732) 632-6400 for replacement options.
Item Number: 2113.46
Manufacturer: AEMC (Chauvin Arnoux)
Part Number: 2113.46
|
|
AEMC Model SR652 AC Current Probe (1000A, 1mV/A, Lead)
The SR652 is a general purpose 1000AAC current probe designed for use with DMMs, loggers and other instruments that have voltage inputs. It has a voltage output proportional to the rate of 1mV per amp to the current measured in the jaw. The SR652 has an integral 5 ft (1.5m) lead terminated by shrouded banana plugs. The rounded jaw design on this probe makes it well-suited for power applications where high accuracy and low phase shift are important.
SR652 AEMC Model SR652 AC Current Probe Features:
-
Measurement range of 100mA to 1200AAC
-
Large jaw opening accommodates conductors up to two 500MCM
-
Improved ergonomic design and easy operation
-
Conforms to EN 61010, 600V Cat. III
-
Low phase shift for power measurement
-
Designed for DMMs, recorders, loggers, oscilloscopes, power and harmonic meters
AEMC Model SR652 AC Current Probe Applications:
AEMC Model SR652 AC Current Probe Specifications:
|
