AEMC Model SR631 AC Current Probe (1000A, 5mA/A, Jack)
Our Price: Unit has been discontinued. Please call (732) 632-6400 for replacement options.
Item Number: 2113.47
Manufacturer: AEMC (Chauvin Arnoux)
Part Number: 2113.47
|
|
AEMC Model SR631 AC Current Probe (1000A, 5mA/A, Jack)
The SR631 is a general purpose 1000AAC current probe designed for use with instruments that require a 5A current input. It has a 1000:5 ration and output of 5mA per amp measured in the jaw. The SR631 has jack output termination that accepts 4mm banana plugs. The rounded jaw design on this probe makes it well-suited for power applications where high accuracy and low phase shift is important.
AEMC Model SR631 AC Current Probe Features:
-
Measurement range of 100mA to 1200AAC
-
Large jaw opening accommodates conductors up to two 500MCM
-
Improved ergonomic design and easy operation
-
Conforms to EN 61010, 600V Cat. III
-
Low phase shift for power measurement
-
Designed for DMMs, recorders, loggers, oscilloscopes, power and harmonic meters
AEMC Model SR631 AC Current Probe Applications:
AEMC Model SR631 AC Current Probe Specifications:
|
