AEMC Model MN213 AC Current Probe (240A, 1mA/A, Lead)
The MN213 is a general purpose AC current probe, which is designed for DMMs and other measuring instruments with current input. It has a 1000:1 ratio and an output of 1mA per Amp in the primary (inside the jaw). The MN213 has integral 5 ft (1.5m) leads terminated by shrouded banana plugs. The MN213 has protective diodes across the output that limits the voltage in the case if the open secondary.
AEMC Model MN213 AC Current Probe Features:
-
Small, compact size
-
Large jaw opening accommodated conductors up to 250MCM
-
Designed for DMMs, loggers, recorders and oscilloscopes
-
Conforms to EN 61010, 600V Cat. III
AEMC Model MN213 AC Current Probe Applications:
-
Measuring in breaker panels
-
Industrial loads
-
HVAC
-
Residential and commercial sites
-
5A secondary current transformers (CTs) monitoring
AEMC Model MN213 AC Current Probe Specifications:
|
