AEMC 502 Clamp On Meter

The Clamp-On Meter Model 501 is a general-purpose professional clamp-on. A strong mechanical case design, quality materials, full ranges and compliance to international safety and quality standards ensure a professional and reliable tool. The Model 501 is a True RMS Clamp On which provides RMS measurements for measuring in non-linear electrical environments.

This clamp-on multimeter is auto-ranging, and provides the user with AAC,VAC, VDC, Ohms, Continuity, as well as a frequency measurement function. The jaw opening for the Model 502 is 1.1" (28mm).

The large and complete 4000-count LCD features comprehensive user interface symbols such as a low battery indicator. It is equipped with a Data Hold function,
which freezes the measurement. The Model 501 is compact for comfortable one-handed operation, and the hooked jaw design is easy to maneuver in crowded wiring and breaker panels. The jaw opening for the Model 501 is 1.1" (28mm).

Features:

• Compact size - fits into your pocket
• 400AAC current measurements
• 600VAC/DC volts measurements
• True RMS measurements
• Resistance measurements to 400 Ohm
• Continuity with beeper below 40 Ohm
• Frequency measurements from V and A
• Hold function to "freeze" readings
• Large easy-to-read 4000-count display
• 42-segment bargraph
• Includes test leads and a soft carrying pouch

Applications:

• Industrial, commercial, HVAC and residential troubleshooting
• Power panel, junction box and battery bank monitoring
• Electrical testing and troubleshooting on traditional and non-linear leads,
  such as adjustable speed drives and computers

Technical Specifications
